About LogicForge

LogicForge is a native Windows circuit workbench created by Michał Trojanowski. It brings digital logic, reusable IC circuits, memory and signal inspection into one editor, with a separate library for electrical projects.

Learn by changing a working circuit

The application includes 20 examples, a guided tutorial and a Home screen for new, recent and example projects. The half adder, RAM and calculator examples connect small Boolean operations to larger systems.

Two kinds of simulation

Digital projects use logic signals, gates and stored state. Electrical projects include components such as resistors, capacitors, voltage sources, diodes and NPN/PNP transistors. These are educational models; results are not a substitute for validating a physical design with the relevant component specifications.

Browser demo and Windows editor

The website provides a single-gate Boolean simulator and a half-adder demo. The complete circuit canvas, project files, custom ICs, RAM and electrical editor are in the Windows application.

Project information

Public documentation, example circuits, issue reporting and installer releases are maintained in the LogicForge GitHub repository. The application is proprietary and its source repository is private. No open-source license is implied by the public documentation.
